FX5-485ADP

Jual Mitsubishi PLC FX5-4AD-ADP

Mitsubishi PLC FX5-4AD-ADP adalah modul analog input (Analog-to-Digital Converter) yang dirancang khusus untuk seri Mitsubishi PLC FX5U dan FX5UC. Modul ini berfungsi untuk membaca sinyal analog dari berbagai sensor dan perangkat lapangan seperti sensor suhu, tekanan, arus, maupun level cairan yang menghasilkan sinyal tegangan atau arus.

FX5-4AD-ADP menyediakan 4 kanal input analog dengan konversi data presisi tinggi dan respons cepat. Modul ini ideal untuk aplikasi industri yang membutuhkan pemantauan dan pengendalian proses secara real-time, seperti sistem HVAC, otomasi pabrik, dan sistem kontrol suhu.

Tingkatkan akurasi kontrol proses industri Anda dengan Mitsubishi PLC FX5-4AD-ADP
Modul input analog presisi tinggi untuk pembacaan sinyal 0–10V dan 4–20mA, ideal untuk integrasi dengan berbagai sensor industri.

💬 Hubungi Prestasi Jaya Maju untuk informasi harga dan ketersediaan stok

Spesifikasi Teknis Mitsubishi PLC FX5-4AD-ADP

  • Seri Kompatibel: Mitsubishi PLC FX5U / FX5UC

  • Model: FX5-4AD-ADP

  • Jenis Modul: Analog Input Adapter

  • Jumlah Kanal Input: 4 channel

  • Jenis Sinyal Input:

    • Tegangan: 0 – 10 V DC, -10 – 10 V DC

    • Arus: 0 – 20 mA, 4 – 20 mA

  • Resolusi Konversi: 12 bit (1/4000)

  • Kecepatan Sampling: ± 2 ms per channel

  • Akurasi: ±0.3% dari F.S. (Full Scale)

  • Isolasi: Photo coupler isolation antara input dan sistem

  • Pemasangan: Dipasang di sisi kanan unit utama PLC

  • Catu Daya Operasi: Diambil langsung dari PLC utama

  • Dimensi (WxHxD): 30 × 90 × 80 mm

  • Berat: ± 100 gram

  • Sertifikasi: CE, UL, RoHS

Tipe Expansion dan Add-On Modules untuk Mitsubishi PLC FX5 Series

1. Expansion Boards (Add-On di slot depan CPU)

Dipasang langsung di slot depan CPU (maks. 1 board per CPU).

Tipe Fungsi
FX5-232-BD RS-232C communication (1 channel)
FX5-485-BD RS-485 communication (1 channel)
FX5-422-BD-GOT GOT connection (RS-422)
FX5-4AD Analog input 4 channel (voltage/current)
FX5-4DA Analog output 4 channel (voltage/current)
FX5-8AD Analog input 8 channel (voltage/current/thermocouple/RTD)

2. Expansion Adapters (Add-On di sisi kiri CPU)

Dipasang di sisi kiri CPU (maks. 4 adapter per CPU, butuh FX5-1PSU-5V jika >2 adapter).

Tipe Fungsi
FX5-232ADP RS-232C (1 channel)
FX5-485ADP RS-485/RS-422 (1 channel)
FX5-4AD-ADP Analog input 4 channel
FX5-4DA-ADP Analog output 4 channel
FX5-CCL-MS CC-Link master (V2)
FX5-CCLGN-MS CC-Link IE Field Basic master
FX5-ASL-M AnyWireASLINK master

3. Expansion Modules (I/O & Special Function)

Dipasang di sisi kanan CPU/expansion (maks. 16 modul tergantung konfigurasi).

Digital I/O Expansion

Tipe Spesifikasi
FX5-8EX/ES 8 input (sink/source)
FX5-16EX/ES 16 input (sink/source)
FX5-8EYR/ES 8 output relay
FX5-8EYT/ESS 8 output transistor (source)
FX5-16EYR/ES 16 output relay
FX5-16EYT/ESS 16 output transistor (source)
FX5-32ER/ES 16 input + 16 output relay
FX5-32ET/ESS 16 input + 16 output transistor

Analog Expansion

Tipe Spesifikasi
FX5-4AD 4 channel analog input
FX5-4DA 4 channel analog output
FX5-8AD 8 channel analog input (multi-type)

Temperature Control

Tipe Spesifikasi
FX5-4LC 4 channel temperature control (TC/RTD)

High-Speed Counter

Tipe Spesifikasi
FX5-16ET/ES-H 16 input + high-speed counter (200 kHz)

Positioning

Tipe Spesifikasi
FX5-20PG-D 2-axis pulse output (open collector)
FX5-20PG-P 2-axis pulse output (differential)

Communication Expansion

Tipe Spesifikasi
FX5-CNV-BUS Bus conversion (ke FX3 series I/O)
FX5-C1PS-5V Power supply untuk expansion adapter

Catatan Penting

  • FX5UC (konektor type) butuh FX5-CNV-IFC untuk pakai expansion module terminal block.
  • FX5-1PSU-5V wajib jika pakai >2 expansion adapter.
  • Maks. I/O total: 512 poin (termasuk remote I/O via CC-Link).
